Rockwell B-1b Lancer

20.6k MsMuseumJanitor  one month ago

The Rockwell B-1 Lancer[b] is a supersonic variable-sweep wing, heavy bomber used by the United States Air Force. It has been nicknamed the "Bone" (from "B-One"). As of 2024, it is one of the U.S. Air Force's three strategic bomber types, along with the B-2 Spirit and the B-52 Stratofortress.

The B-1 has a blended wing body configuration, with variable-sweep wings, four turbofan engines, triangular ride-control fins and a cruciform tail. The wings can sweep from 15 degrees to 67.5 degrees (full forward to full sweep). Forward-swept wing settings are used for takeoff, landings and high-altitude economical cruise. Aft-swept wing settings are used in high subsonic and supersonic flight. The B-1's variable-sweep wings and thrust-to-weight ratio provide it with improved takeoff performance, allowing it to use shorter runways than previous bombers. The length of the aircraft presented a flexing problem due to air turbulence at low altitude. To alleviate this, Rockwell included small triangular fin control surfaces or vanes near the nose on the B-1. The B-1's Structural Mode Control System moves the vanes, and lower rudder, to counteract the effects of turbulence and smooth out the ride.


jkeehs
B-1b Lancer on full afterburner with fully swept wings

Spotlights

General Characteristics

  • Created On Android
  • Wingspan 126.5ft (38.5m)
  • Length 138.9ft (42.3m)
  • Height 31.7ft (9.7m)
  • Empty Weight 19,165lbs (8,693kg)
  • Loaded Weight 36,051lbs (16,352kg)

Performance

  • Power/Weight Ratio 8.976
  • Wing Loading 39.6lbs/ft2 (193.4kg/m2)
  • Wing Area 910.2ft2 (84.6m2)
  • Drag Points 7225

Parts

  • Number of Parts 114
  • Control Surfaces 3
  • Performance Cost 627
