Venture Aeronautics Project C710 "Flapjack"

27.2k TheFlightGuySP  1.2 years ago

GIF GALLERY




Overview: the C710 "Flapjack" is an experimental tailless fighter-bomber with a single 2500hp four-bladed propeller engine. The aircraft, despite being a bit slower than other propeller fighters, has exceptional maneuverability at both low and high speeds, and can out-maneuver many aircraft of similar type. The aircraft features 5x 50lb bombs and two wing-mounted rotary autocannons.


FLIGHT CHARACTERISTICS

Maximum Airspeed (TAS): 400mph, 644kph, ~348knots.
Maximum Altitude: 30,000ft, 9,144m.
Takeoff Airspeed (IAS)(Full Load): ~100mph, ~161kph, ~87knots.
Landing Airspeed (IAS)(Full Load): ~85mph, ~137kph, ~74knots.
Controls:

  • Activate1: Engine Activation.
  • Activate2: Toggle Bombs/Bomb Bay Doors.
  • Trim: Trim.

NOTES

  • The aircraft has a tendency to become hyper sensitive to large control inputs at low airspeed, which can result in a control stall and dramatic aircraft movements.
  • The aircraft may experience slight drifting while on the ground. Expect slight landing gear wobble when turning at higher ground speeds.
  • Do not drop the bomb payload while performing Negative-G maneuvers. I recommend pitching up slightly while dropping the bomb payload.

Spotlights

General Characteristics

  • Created On Windows
  • Wingspan 18.9ft (5.7m)
  • Length 29.9ft (9.1m)
  • Height 10.5ft (3.2m)
  • Empty Weight 2,376lbs (1,077kg)
  • Loaded Weight 5,731lbs (2,599kg)

Performance

  • Horse Power/Weight Ratio 0.436
  • Wing Loading 24.6lbs/ft2 (120.2kg/m2)
  • Wing Area 232.9ft2 (21.6m2)
  • Drag Points 2164

Parts

  • Number of Parts 183
  • Control Surfaces 0
  • Performance Cost 1,010
