The Mil Mi-30 is a soviet concept helicopter,this project from the 90's is for a tilt rotor helicopter like the V-22 and Mil mi response was the Mil-30 this have had 3 variant i D,L,S, i thint this is the L variant made for tactica transport whit a longer cabin mw t to carry araund 40-50 soldiers or some Light Veiches but despite the tactica advance this heli was scrapped due to insufficient budget,technological difficulties and the Soviet Union collapse.
Controlls
Throttle:power(min 65% for takeoff)
VTOL UP rotate engine
Ag-8 gyroscope
Specifications
General Characteristics
- Created On Android
- Wingspan 97.7ft (29.8m)
- Length 75.1ft (22.9m)
- Height 24.0ft (7.3m)
- Empty Weight 21,497lbs (9,751kg)
- Loaded Weight 24,030lbs (10,899kg)
Performance
- Horse Power/Weight Ratio 0.249
- Wing Loading 22.0lbs/ft2 (107.6kg/m2)
- Wing Area 1,090.5ft2 (101.3m2)
- Drag Points 20873
Parts
- Number of Parts 160
- Control Surfaces 5
- Performance Cost 1,022
The D variant of Mi-30, known as Mantis (Mi-30D Mantis) is the military quad tiltrotor aircraft.
@SomeSPGuyWhoLikesLore it have 2 vent at rhe wing base but the engines need to be mounted on the tilt part ,so that one thing this plane fail
Where could the engine be possibly located ❓
