Designation:

AG1 — Engine
AG2 — Crane
AG3 — Missiles

CEROS-200 EO/IR:

Cam1
Cam2

Crane Control:

Pitch
Roll
Trim
VTOL

General Characteristics:

Specification:

• Length: 116m
• Beam: 15m
• Draft: 4.8m
• Displacement: 3600 tons standard to 4250 tons maximum loaded

Propulsion: (CODLAG)

• 1 × GE LM2500 Gas Turbine (1.2Mw)
• 2 × Diesel engine MTU 16V1163 M94 (2.5Mw)
• 2 × INDAR SM Electric Motor (1.8Mw)
• Speed: 35knots

Complement: 65-135

Sensors & Processing systems:

• 3× Saab Sea-Giraffe 4A AESA Multi-Functional Radar
• 1× Saab Sea-Giraffe 1X AESA X-Band Radar
• 2× Saab Ceros 200 Fire Control Radar
• 4× NLWS Naval Laser-waring System
• 1 × Wartsila X-band Navigation radar
• 1 × Wartsila S-band Navigation radar
• 1× Saab Naval COMINT and C-ESM
• 1× Atlas ASO DSQS-24 Hull Mounted Sonar
• 1× Atlas ELEKTRONIK ACTAS Towed Array Sonar
• 1× SATCOM

Electronics Warfare & Decoys:

• 1× Harris ES-3601 Radar-ESM
• 2× MLCS Countermeasure Launching Station

Armament:

• 1× OTO Melara super rapid
• 2× DS30M Mk II Automated Small Calibre Gun
• 8× RGM-84 Harpoon blk.II
• 8× Mk-41 Tactical Module VLS for:



  • 32× RIM-162 ESSM


• or



  • 8 × RUM-139C VL ASROC


• 2×3 Mk-32 torpedo tube for:



  • Mark 54 Lightweight Torpedo



Multi-Mission Module

• Fitted for 2 RHIB/UUV/USV and adaptable capabilities for Swarm UAV

Aircraft Carried:

• 1× S-70Bravo-7 Seahawk
