Friedrichshafen G.III

11.0k Boelin  3.8 years ago

WEEB VERSION (SWORD ART ONLINE)

All information from Wikipedia

Friedrichshafen G.III

The Friedrichshafen G.III (factory designation FF.45) was a medium bomber designed and manufactured by Flugzeugbau Friedrichshafen. They were used by the German Imperial Air Service during World War I for tactical and limited strategic bombing operations. After the end of the war a number of Friedrichshafen bombers were converted into transport aircraft while a small number also saw service as dedicated airliners.

Development

The earlier G.II paved the way for the larger and more powerful G.III, which entered service in early 1917.[1] While it looked somewhat similar to the G.II, the G.III was longer and had a greater wingspan which caused its designers to increase the number of interplane struts to three pairs on each side of the fuselage. Operational experience with the G.II had revealed a tendency for the aircraft to "nose over" during landings with deadly consequences for the nose gunner and possibly also the pilot. Friedrichshafen engineers solved this problem by equipping the G.III with an auxiliary wheel mounted under the nose gunner's position. The G.III also used the more powerful six-cylinder 190 kW (260 hp) Mercedes D.IVa engines. The extra power increased the bomb carrying capability enabling the aircraft to carry a bomb load of up to 1,000 kg (2,200 lb), though this severely reduced operational range. In practice, the heaviest bomb load rarely exceeded 600 kg (1,320 lb). Some of the bomb load could be carried internally but most of it was carried on removable external bomb-racks and usually consisted of streamlined P.u.W bombs but specialized munitions such as air-mines could also be carried. As production continued modifications were made to the G.III series that resulted in further two sub-variants:

Armament

Guns: Usually 2-3 × 7.92 mm (0.312 in) Parabellum MG14 machine guns firing the 7.92×57mm Mauser cartridge.

Bombs: Any combination of 12.5 kg (28 lb), 50 kg (110 lb), 100 kg (220 lb), 300 kg (660 lb) or1,000 kg (2,200 lb) P.u.W bombs or air-mines up to a maximum warload of 1,000 kg (2,200 lb).

Controls

Normal flight controls
AG1= front gunner
AG2= rear gunner
AG3= nothing
AG4= nothing
AG5= nothing
AG6= nothing
AG7= nothing
AG8= nothing

Note:

  • When 60 - 50 mph. Pitch the aircraft slowly or the aircraft will force to pitch up

  • Didn't add a sight because I think that's what causes the plane's file to corrupt and unable to load

  • The Paint scheme looks similar to the Gotha G.IV

HAVE FUN FLYING!!!

Spotlights

General Characteristics

  • Created On Android
  • Wingspan 109.7ft (33.4m)
  • Length 61.2ft (18.6m)
  • Height 19.1ft (5.8m)
  • Empty Weight 20,754lbs (9,414kg)
  • Loaded Weight 22,730lbs (10,310kg)

Performance

  • Horse Power/Weight Ratio 0.109
  • Wing Loading 9.4lbs/ft2 (46.0kg/m2)
  • Wing Area 2,413.8ft2 (224.3m2)
  • Drag Points 25436

Parts

  • Number of Parts 414
  • Control Surfaces 8
  • Performance Cost 1,621
