CH-53E Super Stallion

20.4k MsMuseumJanitor  14 hours ago

The Sikorsky CH-53E Super Stallion

is a heavy lift helicopter operated by the United States military. As the Sikorsky S-80, it was developed from the CH-53 Sea Stallion, mainly by adding a third engine, adding a seventh blade to the main rotor, and canting the tail rotor 20°. It was built by Sikorsky Aircraft for the United States Marine Corps. Developed in the 1970s, it entered service in 1981, and is planned to be in service into the 2030s. It is one of the largest military helicopters in service, and is operated from U.S. Navy ships or from land.


Controls: the usual, there is a gyro on the activation group 1 which gives it auto level and trim angle for hands off stick


kshsks


Special thanks to:

Seemeing - for the C-130 Hercules, used in picture
PaintBrushSP - for the Humvee, used in picture
nwa - for helping with the flight characteristics

Go support them too

Spotlights

General Characteristics

  • Created On Android
  • Wingspan 81.9ft (25.0m)
  • Length 99.1ft (30.2m)
  • Height 28.0ft (8.5m)
  • Empty Weight 23,191lbs (10,519kg)
  • Loaded Weight 44,251lbs (20,072kg)

Performance

  • Power/Weight Ratio 5.446
  • Wing Loading 514.8lbs/ft2 (2,513.3kg/m2)
  • Wing Area 86.0ft2 (8.0m2)
  • Drag Points 15574

Parts

  • Number of Parts 106
  • Control Surfaces 0
  • Performance Cost 709
