ME/BF-109 Series!

The Messerschmitt Bf 109 is a monoplane fighter aircraft that was designed and initially produced by the German aircraft manufacturer Bayerische Flugzeugwerke (BFW). Together with the Focke-Wulf Fw 190, the Bf 109 formed the backbone of the Luftwaffe's fighter force during the Second World War.[3] It was commonly called the Me 109 by Allied aircrew and some German aces/pilots, even though this was not the official model designation.[4]

F-4 variants

The 1,350 PS (1,332 hp, 993 kW) DB 601 E was used in the F-3 and F-4 model together with a VDM 9-12010 propeller with broader blades for improved altitude performance.[35][52] The DB 601 E was initially restricted to 1,200 PS (1,184 hp, 883 kW) at 2,500 rpm;[52] however, the full rating of 1,350 PS at 2,500 rpm was cleared for service use by February 1942. The DB 601 E ran on standard 87 octane "B-4" aviation fuel, despite its increased performance; while the earlier DB 601 N required 100 octane "C-3" fuel.[53]

Only 15 examples of the F-3 are believed to have been produced by Messerschmitt Regensburg between October 1940 and January 1941. Like the F-1, the F-3 was armed with the 20 mm MG-FF/M and two 7.92 mm (.312 in) MG 17s.[54]

From the F-4 onward, the new 20 mm Mauser MG 151/20 with 200 rounds was used as the engine gun (German: Motorkanone).[50] The first F-4s reached frontline units in June 1941. Production lasted exactly a year between May 1941 and May 1942, with 1,841 of all F-4 variants produced.[55] Some of the later models were capable of mounting two 20 mm MG 151/20 cannons under the wing in faired gondolas with 135 rpg. These were designated F-4/R1 and 240 of them were produced by WNF in the first quarter of 1942.[56] This optional additional armament was standardized as field kit for later G and K series. A special high-altitude variant, the F-4/Z featuring GM-1 boost, was also built with a production run of 544 in the first quarter of 1942 and saw extensive use.[53][57] Finally, the Erla factory produced 576 tropicalized F-4 trop in the first half of 1942.

more variants coming soon!
