The guidance method of this missile has been changed from parallel approach to proportional guidance. For usage, please refer to the original author's documentation.
Specifications
General Characteristics
- Created On Android
- Wingspan 5.0ft (1.5m)
- Length 16.4ft (5.0m)
- Height 5.0ft (1.5m)
- Empty Weight N/A
- Loaded Weight 12,787lbs (5,800kg)
Performance
- Power/Weight Ratio 1.054
- Wing Loading 222.9lbs/ft2 (1,088.2kg/m2)
- Wing Area 57.4ft2 (5.3m2)
- Drag Points 804
Parts
- Number of Parts 45
- Control Surfaces 8
- Performance Cost 193
@Rakoval500k No.
You mean parallel approach, predicting in advance the intersection of the missile with the target at the current speed.
The Proportional guidance is this:
If the target azimuth is called the line-of-sight angle (q), then ω (missile angular velocity)=k×dq/dt, where k is the scale factor and k must be greater than 1.
"Proportional" as in "Predicted line of sight"? Might be very good choice for some corrected rockets.
