(AUTO RELOAD+AIM) MK-26 Guided Missile Launching System MOD 2

6,186 TheSmoker  yesterday
Auto Credit Based on CessnaIsCool's Naval Challenge!

Credits to @SpartanSR91 for helping me with the code.

BACKGROUND : MK-26 Guided Missile Launching System


The MK-26 Guided Missile Launching System is one of the last rail-based missile launcher found on American warships such as the VIrginia-class cruiser, Kidd-class destroyer and the Ticonderoga-class cruiser. It can carry the SM-2 SAM and ASROC anti-submarine countermeasures, it was designed in the 1970s by FMC and United Defence. It could carry an impressive 64 missiles within it with an impressive fire rate of 2 missile every 9 seconds with a 1 second salvo delay. Despite its impressive capabilities, it was produced in relatively small numbers as the more capable MK-41 VLS surpassed it soon as the MK-41 had a higher rate of fire and a wider arsenal of different weapons such as the (SM-2, SM-3, SM-6,ASROC and the Tomahawk missile). As a result it was quickly phased out in favour of the MK-41 VLS.
Even though it's time of service within the US navy has long been over, it still in service in the Taiwanese navy aboard the Kee Lung-class destroyers (Kidd-class destroyers)

BACKGROUND : RIM-66 (SM-2MR)


The RIM-66 is a surface to air missile with some anti-ship capability, it was used on a wide variety of weapon system such as the (MK-22,MK-26,MK-41 AND MK-57 PVLS) and more. It was designed in 1963 to replace the aging 3T missiles (RIM-2 Terrier, RIM-8 Talos and RIM-24 Tartar). The SM-2's design came from the older RIM-24 Tartar missile and it uses semi-active radar homing for guidance, it is classified as a medium ranged surface to air missile with anti-ship capability.
It is in service with many countries such as the USA, Japan, Spain and South Korea within their navies.

HOW TO USE :

Select a target and wait for the missiles to finish arming and wait for the arms to point directly at the target then fire both missiles to get it to reload, the arms will then go back to its original position and around 8 secs later it will reload and you repeat the process. Do note that the missiles will crash into the ground if the target is in a dive.

STATS (MK-26 Guided Missile Launching System MOD 2) :

Mass 265,798Kg
Traverse 360 degrees. Traverse rate 90 degrees/sec
Elevation -10 to 90 degrees Elevation rate 50 degrees/sec
Capacity 8X RIM-66L-2 (SM-2 Block IIIa)
Rate of fire 2 missiles every 9 seconds with a 1 second salvo delay.
Functions :
AUTO RELOAD for every salvo + AUTO AIM
Sliding hatches with 135 degree rotation with 80% speed

Stats RIM-66L-2 (SM-2 Block IIIa) :

Payload 60Kg
Range 0-185Km
Speed Mach 3.5
Thrust Force 53378N (Newtons)
Mass 707Kg
Length 4.72m
Diameter 340mm
Proxfuse 8 Meters

PLEASE KEEP UPVOTING GUYS AS IT WOULD REALLY HELP ME CREATE MORE BUILDS FOR YOU
