ATR 42-600

19.3k Pakdaaircraftindustries  7 days ago

Simple ATR!

Now this one is free to use!

The ATR 42 is a regional airliner produced by Franco-Italian manufacturer ATR, with final assembly in Toulouse, France. On 4 November 1981, the aircraft was launched with ATR, as a joint venture between French Aérospatiale (now part of Airbus) and Aeritalia (now Leonardo S.p.A.). The ATR 42-300 performed its maiden flight on 16 August 1984 and type certification was granted during September 1985. Launch customer Air Littoral operated its first revenue-earning flight in December of that year.
The high-wing airliner is powered by two turboprop engines, Pratt & Whitney Canada PW120s. The number "42" in its name is derived from the aircraft's original standard seating capacity of 42 passengers. Later variants are upgraded with new avionics, a glass cockpit, and newer engine versions. The ATR 42 is the basis for the stretched ATR 72, introduced in October 1989.

Design :

The ATR 42 is a straight high-wing airliner with twin turboprops and a T-tail, certified in the transport category, and powered by Pratt & Whitney Canada PW120s. It has deicing boots to fly in icing conditions and a retractable landing gear in fairings under the fuselage, with wheel sides visible in flight. It has no Auxiliary Power Unit (APU), but can still be autonomous in ground operations, as it has a propeller brake on the starboard engine, allowing the engine to remain running to provide power on the ground.

It has a pressurized cabin with a circular cross-section, with a 2.57 m (8 ft 5 in) inside width for four-abreast seating, allowing 48 seats at a 30 in (760 mm) seat pitch. It has a 54.5 m2 (587 sq ft) wing area and a 24.57 m (80.6 ft) wing span, for a 11.1 wing aspect ratio. It has a 18,600 kg (41,000 lb) MTOW, for a 341 kg/m2 (70 lb/sq ft) wing loading. It can reach a cruise speed of 300 kn (560 km/h) true air speed, with a fuel flow of 811 kg/h (1,788 lb/h):[23] a fuel economy of 1.46 kg/km (5.96 lb/nmi) or 3.8 L/100 km (62 mpg‑US) per seat with 48 seats and a jet fuel density of 0.8.

Features and extras... :

#1: if you want to see one in action check my video on the simple planes page! → ATR 42-600 Taxing!

#2 : Action groups

AG/1 : Gyroscope

AG/2 : landing lights

#3 : Free to use!

Paint it , modify it, Make liveries, Just give me credits for the main frame!

#4 : oficial Liveries coming soon! (Maybe) (If I don't make it , take it has a idea)

General Characteristics

  • Created On Android
  • Wingspan 51.2ft (15.6m)
  • Length 47.3ft (14.4m)
  • Height 15.6ft (4.7m)
  • Empty Weight 17,286lbs (7,841kg)
  • Loaded Weight 29,979lbs (13,598kg)

Performance

  • Horse Power/Weight Ratio 0.2
  • Wing Loading 46.4lbs/ft2 (226.4kg/m2)
  • Wing Area 646.5ft2 (60.1m2)
  • Drag Points 8096

Parts

  • Number of Parts 170
  • Control Surfaces 5
  • Performance Cost 778
