Cessna 208B Caravan

18.4k Pakdaaircraftindustries  10 days ago

Simple but looks nice!

The Cessna 208 Caravan is a utility aircraft produced by Cessna. The project was commenced on November 20, 1981, and the prototype first flew on December 9, 1982. The production model was certified by the FAA in October 1984 and its Cargomaster freighter variant was developed for FedEx. The 4 ft (1.2 m) longer 208B Super Cargomaster first flew in 1986 and was developed into the passenger 208B Grand Caravan.[2]

The strutted, high wing 208 typically seats nine passengers in its unpressurized cabin, is powered by a single Pratt & Whitney Canada PT6A tractor turboprop and has a fixed tricycle landing gear, floats, or skis.[3]

By 2022, 3,000 had been delivered and 24 million flight hours have been logged. Caravans have been used for flight training, commuter airlines, VIP transport, air cargo, skydiving and humanitarian missions.

Design:

The Cessna 208 is a high-wing braced cabin monoplane powered by a single Pratt & Whitney Canada PT6A turboprop in tractor configuration. The cabin has room for nine passengers and two crew when used as a passenger aircraft with four doors: one for each crew member, an airstair door on the right side of the cabin and a cargo door on the left. The aircraft can be optionally fitted with an underslung cargo pod.[3]

The basic 208 airframe has a fixed tricycle landing gear but can also be fitted with various types of landing gear, allowing it to operate in a wide variety of environments. Some common adaptations include floats with retractable landing gear on the Caravan Amphibian model, and skis

The Caravan interior can be outfitted with seats or as a cargo compartment. The standard high-density airline configuration has four rows of 1-2 seating behind the two seats in the cockpit. This variant is capable of holding up to thirteen passengers, although it is marketed as being able to make a profit carrying just four.[14]

The cabin can be configured in a low density passenger configuration, with 1-1 seating, as a combination of passengers and cargo, or as a strictly cargo aircraft.[15] Many variants include an underbelly cargo pod, which can be used for additional freight capacity, or for passenger baggage. A number of Caravans are operated as skydiving aircraft with the left-side cargo hatch converted to a roll-up door.[16]

The airplane typically seats nine passengers with a single pilot, although with a FAR Part 23 waiver it can seat up to fourteen passengers. The aircraft is also used for cargo operations.[3]

The short-fuselage Caravan burns 48 US gal (180 L) of fuel per hour at 170 kn (310 km/h; 200 mph) for 200 nmi (370 km; 230 mi) stages

General Characteristics

  • Created On Android
  • Wingspan 78.7ft (24.0m)
  • Length 57.0ft (17.4m)
  • Height 22.0ft (6.7m)
  • Empty Weight 11,153lbs (5,059kg)
  • Loaded Weight 19,314lbs (8,760kg)

Performance

  • Horse Power/Weight Ratio 0.31
  • Wing Loading 23.3lbs/ft2 (113.8kg/m2)
  • Wing Area 828.9ft2 (77.0m2)
  • Drag Points 7125

Parts

  • Number of Parts 98
  • Control Surfaces 7
  • Performance Cost 417
