The Northrop F-5 is a family of supersonic light fighter aircraft initially designed as a privately funded project in the late 1950s by Northrop Corporation. There are two main models: the original F-5A and F-5B Freedom Fighter variants, and the extensively updated F-5E and F-5F Tiger II variants. The design team wrapped a small, highly aerodynamic fighter around two compact General Electric J85 engines, focusing on performance and a low cost of maintenance. Smaller and simpler than contemporaries such as the McDonnell Douglas F-4 Phantom II, the F-5 costs less to procure and operate, making it a popular export aircraft. Though primarily designed for a day air superiority role, the aircraft is also a capable ground-attack platform. The F-5A entered service in the early 1960s. During the Cold War, over 800 were produced through 1972 for US allies. Despite the United States Air Force (USAF) not needing a light fighter at the time, it did procure approximately 1,200 Northrop T-38 Talon trainer aircraft, which were based on Northrop's N-156 fighter design. After winning the International Fighter Aircraft Competition, a program aimed at providing effective low-cost fighters to American allies, in 1972 Northrop introduced the second-generation F-5E Tiger II. This upgrade included more powerful engines, larger fuel capacity, greater wing area and improved leading-edge extensions for better turn rates, optional air-to-air refueling, and improved avionics, including air-to-air radar. Primarily used by American allies, it remains in US service to support training exercises. It has served in a wide array of roles, being able to perform both air and ground attack duties; the type was used extensively in the Vietnam War.[2] A total of 1,400 Tiger IIs were built before production ended in 1987. More than 3,800 F-5s and the closely related T-38 advanced trainer aircraft were produced in Hawthorne, California.[3] The F-5N/F variants are in service with the United States Navy and U
Specifications
General Characteristics
- Created On Windows
- Wingspan 54.6ft (16.6m)
- Length 67.6ft (20.6m)
- Height 17.7ft (5.4m)
- Empty Weight 45,074lbs (20,445kg)
- Loaded Weight 60,912lbs (27,629kg)
Performance
- Power/Weight Ratio 3.32
- Wing Loading 92.1lbs/ft2 (449.7kg/m2)
- Wing Area 661.3ft2 (61.4m2)
- Drag Points 5726
Parts
- Number of Parts 135
- Control Surfaces 5
- Performance Cost 1,015
Very accurate 👍
