Entwicklung E 50

38.8k Sakorsky  5 days ago

Standardpanzer.


Description:

The E 50 (Entwicklungsfahrzeug 50) is a German prototype tank designed as a medium tank, but is a heavy tank by weight and dimensions. Often called E 50 Standardpanzer. The E 50's chassis is simplified drastically compared to the Panther F and is of modular design, allowing for quicker and cheaper production, as well as fast repairs - a proposed 25 minutes for removal and replacement of the front plate.

The E-50 and E-75 "Standardpanzers" were intended to replace the Panther and Tiger II tanks. For ease of manufacture, both vehicles were to be built on the same production lines, and share as many components as possible.


Pictures:


Blueprint used:


Gallery:


All screenshots done by BMilan.

Link to my E 100
Link to my JgPz E 100


Credits:

-BMilan for consistently amazing screenshots, bro deserves some love.
-Vis for giving me a code that limits gun deppresion angle within 30° of turret rotation, and engine code that limits speed forwards/reverse.

Controls are as usual.

Enjoy.

Spotlights

General Characteristics

  • Created On Android
  • Wingspan 12.1ft (3.7m)
  • Length 34.5ft (10.5m)
  • Height 9.1ft (2.8m)
  • Empty Weight 50,617lbs (22,959kg)
  • Loaded Weight 68,342lbs (30,999kg)

Performance

  • Wing Loading N/A
  • Wing Area 0.0ft2 (0.0m2)
  • Drag Points 5780

Parts

  • Number of Parts 805
  • Control Surfaces 0
  • Performance Cost 2,834
