[PEA] Mikoyan-Gurevich MiG-21

38.1k EagleMan010  4 days ago

Part efficient aircraft


its been a while since I made a mig-21, not sure when but it was quite a while ago

info

The Mikoyan-Gurevich MiG-21 (Russian: Микоян и Гуревич МиГ-21; NATO reporting name: Fishbed) is a supersonic jet fighter and interceptor aircraft, designed by the Mikoyan-Gurevich Design Bureau in the Soviet Union. Its nicknames include: "Balalaika", because its planform resembles the stringed musical instrument of the same name; "Ołówek", Polish for "pencil", due to the shape of its fuselage,[2] and "Én Bạc", meaning "silver swallow", in Vietnamese.
Approximately 60 countries across four continents have flown the MiG-21, and it still serves many nations seven decades after its maiden flight. It set aviation records, becoming the most-produced supersonic jet aircraft in aviation history, the most-produced combat aircraft since the Korean War and, previously, the longest production run of any combat aircraft.
The MiG-21 jet fighter was a continuation of Soviet jet fighters, starting with the subsonic MiG-15 and MiG-17, and the supersonic MiG-19. A number of experimental Mach 2 Soviet designs were based on nose intakes with either swept-back wings, such as the Sukhoi Su-7, or tailed deltas, of which the MiG-21 would be the most successful.

Development of what would become the MiG-21 began in the early 1950s when Mikoyan OKB finished a preliminary design study for a prototype designated Ye-1 in 1954. This project was very quickly reworked when it was determined that the planned engine was underpowered; the redesign led to the second prototype, the Ye-2. Both these and other early prototypes featured swept wings. The first prototype with the delta wings found on production variants was the Ye-4. It made its maiden flight on 16 June 1955 and its first public appearance during the Soviet Aviation Day display at Moscow's Tushino airfield in July 1956.
In the West, due to the lack of available information, early details of the MiG-21 often were confused with those of similar Soviet fighters of the era. In one instance, Jane's All the World's Aircraft 1960–1961 listed the "Fishbed" as a Sukhoi design and used an illustration of the Su-9 'Fishpot'.
The MiG-21 was the first successful Soviet aircraft combining fighter and interceptor characteristics in a single aircraft. It was a lightweight fighter, achieving Mach 2 with a relatively low-powered afterburning turbojet, and is thus comparable to the American Lockheed F-104 Starfighter and Northrop F-5 Freedom Fighter and the French Dassault Mirage III.[1] Its basic layout was used for numerous other Soviet designs; delta-winged aircraft included the Su-9 interceptor and fast Ye-150 prototype from the MiG bureau, while the successful mass-produced frontline fighter Su-7 and Mikoyan's I-75 experimental interceptor combined a similar fuselage shape with swept-back wings. However, the characteristic layout with the shock cone and front air intake did not see widespread use outside the USSR and ultimately proved to have limited development potential, mainly due to the small available space for the radar.

controls

VTOL Down=Flaps
AG1=Drag chute
AG2=N/A
AG3=N/A
AG4=N/A
AG5=N/A
AG6=N/A
AG7=N/A
AG8=N/A
Afterburner activates at >98% throttle
Slight pitch up behavior remains even after tuning, use trim as needed for smooth flight experience

Spotlights

General Characteristics

  • Created On Android
  • Wingspan 23.8ft (7.3m)
  • Length 51.7ft (15.8m)
  • Height 13.1ft (4.0m)
  • Empty Weight 22,238lbs (10,087kg)
  • Loaded Weight 30,479lbs (13,825kg)

Performance

  • Power/Weight Ratio 2.433
  • Wing Loading 93.6lbs/ft2 (457.0kg/m2)
  • Wing Area 325.6ft2 (30.3m2)
  • Drag Points 2412

Parts

  • Number of Parts 89
  • Control Surfaces 5
  • Performance Cost 403
