Su-7 [Fitter-A]

37.4k EagleMan010  2 months ago

after a month, I got an idea, why not a soviet tube that is a brick at low speeds

am very sorry for low quality post

anyways here's the overview

The Sukhoi Su-7 (NATO designation name: Fitter-A) is a swept wing, supersonic fighter aircraft developed by the Soviet Union in 1955. Originally, it was designed as a tactical, low-level dogfighter, but was not successful in this role. On the other hand, the soon-introduced Su-7B series became the main Soviet fighter-bomber and ground-attack aircraft of the 1960s. The Su-7 was rugged in its simplicity, but its Lyulka AL-7 engine had such high fuel consumption that it seriously limited the aircraft's payload, as even short-range missions required that at least two hardpoints be used to carry drop tanks rather than ordnance.
After Joseph Stalin's death, the Sukhoi OKB was reopened[2] and by the summer, it began work on a swept-wing front-line[N 1] fighter. The first prototype, designated S-1, was designed to use the new Lyulka AL-7 turbojet engine. It was the first Soviet aircraft to utilize the all-moving tailplane and a translating centerbody, a movable inlet cone in the air intake for managing airflow to the engine at supersonic speeds.[3] The aircraft also had a wing sweep of 60°, irreversible hydraulically boosted controls, and an ejection seat of Sukhoi’s own design.[2]

The S-1 first flew on 7 September 1955 with A. G. Kochetkov at the controls. Fitted with an afterburning version of the AL-7 engine after the first eleven flights, the prototype set a Soviet speed record of 2,170 km/h (1,170 kn, 1,350 mph, Mach 2.04) in April 1956.[3] The prototype was intended to be armed with three 37 mm Nudelman N-37 cannons and 32 spin-stabilized 57 mm (2.25 in) unguided rockets in a ventral tray.[3] The second prototype, S-2, introduced some aerodynamic refinements. Testing was complicated by the unreliable engine, and S-1 was lost in a crash on 23 November 1956, killing its pilot I. N. Sokolov.[2] Only 132 have been produced between 1957 and 1960, and the aircraft entered service as Su-7 in 1959.

AG1 is the Drag parachute

Vtol down is flaps

here's some screen


enjoy

Spotlights

General Characteristics

  • Created On Android
  • Wingspan 26.9ft (8.2m)
  • Length 55.8ft (17.0m)
  • Height 15.4ft (4.7m)
  • Empty Weight 12,489lbs (5,665kg)
  • Loaded Weight 18,293lbs (8,297kg)

Performance

  • Power/Weight Ratio 2.579
  • Wing Loading 55.3lbs/ft2 (269.8kg/m2)
  • Wing Area 331.0ft2 (30.8m2)
  • Drag Points 3432

Parts

  • Number of Parts 74
  • Control Surfaces 7
  • Performance Cost 357
