Mikoyan Gurevich SM-12

21.3k Moonraker  7 months ago
100 downloads
Auto Credit Based on Moonraker's Free to use MiG-19/SM-12

Press the Auto Credit above to get the free part

MiG SM-12


In its definitive form the ultimate extrapolation of the basic MiG-19 design, the SM-12 evolved, by a process of incremental modification, as a mixed-power point defence interceptor. As the MiG-19S was phased into service with the VVS mid-1956, the MiG OKB was continuing the refinement of the Izdeliye SM twin-engined fighter initiated in 1951 with the SM-1 (I-340). The SM-12 first saw life as an exercise in drag reduction by means of new air intake configurations, and the first of three prototypes, the SM-12/1, was essentially a MiG-19S with an extended and straight-tapered nose with sharp-lipped orifice and a pointed, two-position shock cone on the intake splitter.


Spotlights

General Characteristics

  • Predecessor Free to use MiG-19/SM-12
  • Created On Android
  • Wingspan 32.8ft (10.0m)
  • Length 49.8ft (15.2m)
  • Height 14.4ft (4.4m)
  • Empty Weight -39,244lbs (-17,801kg)
  • Loaded Weight 15,680lbs (7,112kg)

Performance

  • Power/Weight Ratio 12.898
  • Wing Loading 48.9lbs/ft2 (238.8kg/m2)
  • Wing Area 320.6ft2 (29.8m2)
  • Drag Points 6364

Parts

  • Number of Parts 132
  • Control Surfaces 5
